Kvaser DRVlin
EAN: 73-30130-10018-3
A Kvaser DRVcan is a combined cable, connector and CAN bus driver for the LAPcan /
LAPcan II PCMCIA CAN interface. The DRVcans are interchangeable and designed for
maximum flexibility and maintainability.
Share
A Kvaser DRVcan is a combined cable, connector and CAN bus driver for the LAPcan /
LAPcan II PCMCIA CAN interface. The DRVcans are interchangeable and designed for
maximum flexibility and maintainability.
-
DRVcan 251 and DRVcan 1050 are
for normal, high-speed ISO 11898 CAN bus systems. -
DRVcan Dnopto is also intended
for normal, high-speed ISO 11898 CAN bus systems but is equipped with
optocouplers.
-
DRVcan 1053 and DRVcan 1054
are for fault-tolerant CAN buses (sometimes called "low-speed
CAN") -
DRVcan Fi employs optical
fiber and is used for special applications. Different physical
layers are supported through different product versions. -
DRVcan TnT is used with Truck and Trailers, ISO
11992-1 -
DRVcan S is used with
Single-Wire CAN (SAE J2411, GMLAN) -
DRVlin is used with the LIN
bus. Please note that not note that not all applications listed under Application Support for
LAPcan/LAPcan II support the DRVlin.
1-20 kbps
Hardware
CE
1
Yes
No
No
PCMCIA
500 mm
PC-ABS
8000 mps
8000 mps
Win XP, Linux, Win 7, Win Vista, Win 10, Win 8
Yes
No
50 g
Kvaser Leaf LIN and Kvaser DRVlin firmware upgrade.
Windows drivers for all our CAN hardware. Please check the release notes for information on which Windows versions are supported. The package also contains a driver for a virtual CAN bus, for testing and evaluation when you don't have access to a physical CAN bus.
A free of charge LIN bus viewer. This demo version only operates in slave mode and only monitors the LIN bus. Works with Kvaser Leaf Professional LIN and Hybrid family of products.
Library for National Instrument's LabView for all Kvaser LIN hardware.
Software development kit - everything you need to develop software for the Kvaser CAN and LIN interfaces. Libraries, header files, sample programs for e.g. C, C++, C#, Visual Basic and Delphi, documentation, and more. Note: you need to download and install the appropriate device drivers separately.
